What Are Reverse Engineering Services?

Reverse engineering is the process of creating accurate CAD models, engineering drawings, and manufacturing data from existing physical parts, assemblies, or products. Using advanced 3D scanning technologies, point cloud processing, metrology-grade measurement systems, and CAD reconstruction techniques, engineers can recreate legacy components, obsolete parts, tooling, molds, aircraft structures, industrial equipment, and complex assemblies.

Organizations use reverse engineering to replace obsolete parts, modernize legacy engineering data, support Digital Twin initiatives, improve manufacturability, create replacement components, and preserve critical engineering knowledge. CAD/CAM Services provides reverse engineering services for aerospace, defense, industrial equipment, automotive, shipbuilding, energy, and government organizations worldwide.

We can provide

Native CATIA Models
Siemens NX Models
Creo Models
SolidWorks Models
Autodesk Inventor Models
STEP Files
Manufacturing Drawings, often called 2D Shop drawings
GD&T Documentation
MBD / PMI
Digital Twin Models
Technical Data Packages (TDP)
Point Cloud Processing

Why Choose CAD/CAM Services?

Reverse engineering specialists since 1988
Millions of CAD models completed
100+ engineers and drafters
CATIA, NX, Creo, SolidWorks, and Inventor experts
Aerospace, defense, industrial, and government experience
U.S.-based engineering team
ITAR-capable projects
Model-Based Definition (MBD) expertise
Digital Twin and engineering modernization support

Aerospace Reverse Engineering

CAD/CAM Services provides professional aerospace reverse engineering services for commercial aviation, military aircraft, UAVs, aerospace suppliers, and MRO organizations. Our engineering team recreates accurate CAD models, engineering drawings, loft data, and manufacturing documentation from existing aircraft components, legacy engineering records, point clouds, and physical parts. We support aircraft reverse engineering projects involving aircraft modernization, airframe structures, sheet metal components, tooling, fixtures, interiors, and legacy aerospace systems. Whether you need CATIA models, Digital Twin development, or replacement part documentation, our team can help extend the life of critical aerospace assets while preserving valuable engineering knowledge.

Capabilities Include:

Aircraft modernization
Legacy airframe support
Loft data recreation
Sheet metal flattening
CATIA modeling
Digital Twin development
Engineering drawing recreation
CAD data modernization

Defense Reverse Engineering

CAD/CAM Services supports defense reverse engineering initiatives for military platforms, sustainment programs, government agencies, defense contractors, and aerospace manufacturers. Our engineers help organizations recreate engineering data for obsolete components, aging systems, military vehicles, aircraft structures, tooling, and support equipment when original CAD files or drawings are unavailable. We develop Technical Data Packages (TDPs), manufacturing drawings, CAD models, and engineering documentation to support lifecycle extension, modernization, and operational readiness programs. Reverse engineering is often the fastest and most cost-effective method for replacing obsolete components and supporting long-term sustainment requirements.

Capabilities Include:

ITAR-controlled programs
Technical Data Packages (TDP)
Sustainment programs
Obsolete parts recreation
Legacy system modernization
Engineering documentation recovery
CAD remastering
Digital modernization initiatives

Industrial Equipment Reverse Engineering

Our industrial equipment reverse engineering services help manufacturers, utilities, processing facilities, and industrial organizations recreate engineering data for legacy machinery and production equipment. When OEM support ends or engineering documentation is lost, our team can reverse engineer replacement components, assemblies, tooling, and equipment to support continued operation. We create fully editable CAD models, manufacturing drawings, inspection documentation, and Digital Twin assets that allow organizations to modernize engineering records, improve maintenance planning, and reduce downtime caused by obsolete equipment.

Capabilities Include:

Replacement parts
Legacy machinery support
Manufacturing support
Equipment modernization
CAD model creation
Engineering drawing generation
Digital Twin development
Maintenance and lifecycle support

Tool & Die Reverse Engineering

CAD/CAM Services provides comprehensive mold reverse engineering and tool-and-die reverse engineering services for manufacturers, mold makers, and product development organizations. Our engineers can recreate molds, dies, tooling, fixtures, and production equipment from physical components, scan data, or incomplete engineering records. Reverse engineering allows organizations to repair damaged tooling, create replacement components, implement design improvements, and generate modern CAD documentation for future manufacturing needs. Whether supporting injection molding, stamping, casting, or production tooling, our team delivers accurate CAD models and manufacturing documentation that reduce risk and improve productivity.

Capabilities Include:

Mold design reconstruction
Mold reverse engineering
Die repair and restoration
Tool modifications
Injection molding support
Production tooling documentation
CAD modernization
Replacement tooling components

Reverse Engineering for Digital Twin and Engineering Data Modernization

Many organizations use reverse engineering as the first step toward creating a Digital Twin of legacy equipment. By converting physical assets into accurate CAD models and engineering documentation, organizations can modernize decades of engineering data, improve maintenance planning, support lifecycle management initiatives, and reduce dependence on aging paper records and obsolete drawings.

CAD/CAM Services supports Digital Twin, Digital Thread, Model-Based Definition (MBD), and engineering data modernization initiatives through advanced reverse engineering and CAD reconstruction services.

For example, we just finished remastering the entire Northrup Grumman E-2D surveillance plane.

Reverse Engineering vs 3D Scanning

E-2D Hawkeye Aircraft Modernization :- Recent projects include reverse engineering and CAD modernization efforts supporting military aircraft, aerospace structures, industrial equipment, tooling systems, and legacy manufacturing assets.
This are multi-year, multi-million dollar projects.

Obsolete Industrial Gearbox :- Created CAD models and manufacturing drawings from a worn casting no longer supported by the OEM.

Tool & Die Recovery :- Reconstructed tooling from damaged mold components and scan data.

Request A QUOTE

Reverse Engineering Services | CAD Models, Drawings & Digital Twins Since 1988

REQUEST A QUOTE

No items found.

No items found.

REQUEST A QUOTE

REQUEST A QUOTE

No items found.

Case Studies

37% Lighter Trolley Cart for FleetPride — Validated in Ansys

FleetPride's axle trolley cart redesigned in Ansys — 37% lighter (210 lbs → 132 lbs) while maintaining full 1,000 lb rated capacity.

explore

Reverse Engineering a Legacy Rotor Shaft

A client needed a replacement rotor shaft for industrial equipment. Original CAD files, drawings, and specifications were unavailable.

explore

Engine Housing Reverse Engineering

In this case study, we aimed to create a full digital model of an engine casing. This casing had no current CAD files, outdated drawings, and undocumented shapes because of years of use and part changes.

explore

Fan Housing Recreation

We were recently tasked with recreating a fan housing using only the client’s original paper drawings.

explore

CAD Modeling of an F‑16 from 3D Scan to Simulation-Ready

This case study describes how we helped a defense customer turn a dense point cloud into a usable surface model. This model was a CAD surface for an F‑16 that could feed straight into simulation.

explore

AFT Closure Beam Assembly – Aerospace Structure

Our team received the job of creating a detailed 3D CAD model of the AFT closure beam. This beam is an important part of the back fuselage. It helps with load transfer and connects with skins, bulkheads, and closure parts.

explore

Building Helicopter Parts With CATIA Composites Design Workbench

Need help with your own CATIA composites or other CAD related project? Give us a shout, and we’ll saddle up to help you out!

explore

Modernized Engineering Data Repository

Speeds Delivery Time in Urgent Situations for Tinker Air Force Base

explore

3D Scanning of Impeller by Laser and Computer Tomography

Sometimes due to the unavailability of spare parts, you have to make them yourself. This is the story of how we helped our client to recreate the missing parts with a full range of CAD design services: from CT scanning (due to complicated geometry) to...

explore

Automotive Design from 3D Scans

Though 3D scans post-processing is more time and resource-consuming, it is impossible to recreate an original design from poor quality scans.

explore

CAD Migration with Custom Standard

Despite being a relatively old industry, CAD software is still rapidly developing. This makes manufacturers change their focus CAD software. The migration process can be very time consuming, especially when you have your standards. We have proven that...

explore

Design Improvement through Reverse Engineering

Sometimes photos alone can be a sufficient input for a CAD Perfect™ reverse engineering.

explore

Existing Design Modification

Even traditional sports with a long history can benefit from modern CAD technologies. New things can be created without breaking old rules. Parametric modeling helped us to create new putter head designs.

explore

Managing Critical Drawings: Our Take on Central Arizona Project

Infrastructure as intricate as Central Arizona Project’s (CAP) involves complex drawings that need to be continuously monitored and updated.

explore

Part Catalog for Amazon

Preliminary to Amazon’s Phase 1 roll-out of a parts catalog in Amazon Supply, they needed to have 3D CAD images and files for more than 150,000 products — some with as many as 9 different file variations. The problem was how to get 1 M parts files acc...

explore

Pipe Flow Calculation for a Hydroelectric Power Plant

This is the story of how we recreated the piping system from old yellow drawings with 3D modeling and even made liquid run through it. This project involved a full range of services: digitizing old paper drawings, creating 3D CAD models, and running simulations,...

explore

REVERSE ENGINEER TURBINE IMPELLER TO A SOLIDWORKS MODEL FOR CNC

Our client, a multinational firm, is a leading maintenance company, providing maintenance services of all the machinery equipment, is often confronted with an issue of non-availability of machine parts, either due to outdated machinery or a certain modification from the stock part may be required for performance improvement, this leads them to have the specific part remanufactured. For remanufacturing they require a design and CAD / CAM services is the firm they contact to reverse engineer any design. CAD / CAM services is a top-notch firm, providing services in reverse engineering, 3D Scanning, CAD conversion, 3D modelling, Designing and manufacturing codes.

explore

Surface Modeling for Engine Cover Production

How we adopted sheet metal design practices to the needs of the textile industry.

explore

FAQ’s

Reverse Engineering FAQs

What do you guys need to provide me with accurate pricing?

We need to know whether you need your parts to be scanned by us. Or many times we can work with 3D scans provided by third-party companies. The quality of the scan is everything in our business. Anyway, we strongly advise you to use us for both the scanning and the CAD conversion aspects. That way, we can control the quality. Sometimes we receive poor quality scans which make it impossible to create truly Cad Perfect™ models for you. By all means, send us a couple of even cell phone photos, and the rough size of the object. Most of the time, this will provide us enough information to provide a real bid.

The price depends on the part complexity, size, as well as the target file parametres. We need to know whether you need full parametric models, and your desired accuracy. If you tell us the purpose of reverse-engineered models, we can often provide you with possible solutions. The target CAD software may change the price as well. This includes sophisticated Workstation add-on products such as Composites, Catia electrical wiring, mold design, and others.

What is reverse engineering?

Reverse engineering is the process of analyzing an existing physical object, product, component, assembly, or system to understand its design, dimensions, materials, and functionality so it can be recreated, modified, documented, or manufactured again.

In the CAD and engineering world, reverse engineering typically involves converting a physical part into accurate 3D CAD models, 2D drawings, and engineering documentation.

We often: 1) Capture Existing Data by 3D scanning, 2) create a Digital model, often called a Point Cloud, 3) build a 3D model, and 4) produce the required engineering documentation.

How accurate is reverse engineering?

Typical Accuracy Ranges

Hand Measurements (Calipers, Micrometers) ±0.001" to ±0.010"

Structured Light Scanning ±0.001" to ±0.005"

Laser Scanning ±0.002" to ±0.010"

Photogrammetry ±0.010" to ±0.100"+

CMM Measurement ±0.0001" to ±0.001"

Hybrid Scan + CMM Validation ±0.0005" to ±0.002"

‍

For aerospace, medical, and precision manufacturing applications, a combination of 3D scanning and CMM inspection is often used to achieve the highest accuracy.

Also, there can be two parts to this answer: 1) The accuracy of the scanner, and then 2) if we are going all the way to an editable feature-rich CAD file. If we are going all the way to the CAD file, we are within ±.005” of any Point Cloud data.

What is the difference between 3D scanning and reverse engineering?

Many people use the terms 3D scanning and reverse engineering interchangeably, but they are not the same thing.

3D scanning is the process of capturing an object's geometry. Reverse engineering is the process of converting that captured data into usable engineering information, such as CAD models, drawings, and manufacturing documentation.

Simple Explanation

Think of it this way:

3D Scanning = Data Collection = a picture of 1,000,000 dots in 3D space
Reverse Engineering = Engineering Reconstruction = a feature rich, editable CAD Perfect® CAD file.

A 3D scanner captures the shape of an object. Reverse engineering transforms that shape into an intelligent, editable CAD model that engineers and manufacturers can use.

Can you reverse engineer obsolete parts?

Yes. Reverse engineering obsolete parts is one of the most common reasons organizations pursue reverse engineering services.

When original manufacturers no longer support a component—or when CAD files, drawings, tooling, and engineering records have been lost—reverse engineering can recreate the engineering data needed to manufacture replacement parts and extend the life of critical equipment.

Why Obsolete Parts Need Reverse Engineering

Organizations often face situations where:

The original manufacturer is no longer in business.
Replacement parts are unavailable.
CAD files and drawings have been lost.
Legacy equipment remains operational and critical.
Lead times for replacement equipment are too long.
Modern equivalents are incompatible with existing systems.

Rather than replacing an entire machine, reverse engineering allows companies to reproduce the specific component that has become unavailable.

Can you reverse engineer a part without drawings?

Yes. In fact, most reverse engineering projects begin with no drawings, CAD files, or engineering documentation at all.

Engineers can reverse engineer a part using the physical component itself, measurements, 3D scanning, inspection equipment, and engineering analysis to recreate the original design.

How much does reverse engineering cost?

Typical Reverse Engineering Cost Ranges

Simple Part $500–$2,500

Mechanical Assembly $2,000–$15,000

Tool & Die Reverse Engineering $5,000–$50,000+

Point Cloud to CAD $1,000–$100,000+

Aircraft & Defense Projects Custom Quote

‍

Factors That Influence Cost

Part Complexity

A simple machined block with a few holes may require only a few hours of engineering effort, while a complex casting with freeform surfaces can require significantly more modeling time.

Part Size

Larger parts generally require:

More scanning time
More measurement data
More CAD reconstruction effort

Can reverse engineering create a Digital Twin?

Yes. Reverse engineering is often the first step in creating a Digital Twin, especially when original CAD models, engineering drawings, or product data are unavailable.

A Digital Twin is a digital representation of a physical asset that accurately reflects its geometry, structure, and, in many cases, its operational behavior. Reverse engineering provides the engineering data needed to build that digital representation.

How Reverse Engineering Supports Digital Twin Creation

When an organization has a legacy asset with limited or missing documentation, engineers can:

Capture the physical asset using 3D scanning and measurement technologies.
Create accurate CAD models through reverse engineering.
Generate engineering documentation and metadata.
Integrate the resulting models into simulation, PLM, BIM, IoT, or asset management systems.
Establish a Digital Twin that can be updated throughout the asset's lifecycle.

What CAD software do you support?

Can you create manufacturing drawings from a scanned part?

Yes. Manufacturing drawings can be created from a scanned part, but the process involves more than simply scanning the component.

A 3D scan captures the physical geometry of the part, while engineers use reverse engineering techniques to create an accurate CAD model and generate production-ready manufacturing drawings.

The final drawing package may include:

Orthographic views
Dimensions
Tolerances
GD&T
Material specifications
Surface finish requirements
Notes and callouts
Bill of Materials (BOM)

Do you support aerospace and defense reverse engineering?

Yes. Aerospace and defense reverse engineering is a specialized engineering service used to recreate, modernize, and support legacy aircraft, military systems, ground support equipment, tooling, and mission-critical components when original engineering data is unavailable or obsolete.

Organizations throughout the aerospace and defense industries use reverse engineering to maintain operational readiness, extend service life, and create modern digital engineering assets for aging platforms.

Why Choose CAD/CAM Services?

Reverse engineering specialists since 1988
Millions of CAD models completed
100+ engineers and drafters
CATIA, NX, Creo, SolidWorks, and Inventor experts
Aerospace, defense, industrial, and government experience
U.S.-based engineering team
ITAR-capable projects
Model-Based Definition (MBD) expertise
Digital Twin and engineering modernization support

3D Scanning FAQs

How much does scanning services cost?

It depends on the complexity of the scanned model and material properties. As, for example, it may be much more complicated to properly scan an object with a reflective surface, than a non-reflective surface. It also depends on three main factors:

the physical size of your part
the required scanning resolution
if industrial CT or metallurgy scanning is needed

Simple quick cell phone photos are worth a thousand words to us. To know for sure you can request a quote. It is of course, free – and treated as if an NDA is already in place.

Some averages:

The typical 3D scan is somewhere around $200-400 per part.
Tomographic (CT) scanning is $600-900 per part.

Because so much of our business is Aerospace related, our scanning – and the completed CAD file HAS to be within ±.005” anywhere on that part, we never use consumer-grade scanners. The scanners we use start at $25,000 and go up to $700,000 (CT) per scanner.

At any given time, we have in excess of $ 5 million just in scanning hardware we use. In addition, a hidden factor of scanning on any system is the assembly and clean up of any scan. The rule of thumb is a 2-1 ratio. So even with our experienced scanning staff, if we spend one-hour scanning; we will then spend an additional two hours of clean up and assembly before our CAD group gets the Point Cloud file to simulate or reverse engineer.

What is the Point Cloud/Mesh/3D Scan?

A point cloud is thousands if not millions of data points located in space by X, Y, Z coordinates. Images of this nature are often captured with Faro Focus or Artec scanners that specialize in large-area scanning. Most likely you obtain building and territory plans in this file format.

‍

A polygon mesh is a set of triangles located in the same manner. These scans are obtained with Artec, Creaform, Enscan and other handheld scanners. Parts and reverse engineering device scans are usually polygon meshes.

What types of scanners do you use?

Faro Arm – Very good for most parts, fast and accurate
Turntable scanners – high accuracy, high detail, fast scanning. Great for smaller parts.
Portable handheld – may be favorable for some larger parts – if not a tripod-mounted scanner.
Long Range – these mount on a tripod, and are intended to scan buildings, plants, and other larger sized projects.
Industrial CT scanners – incredibly expensive, but they offer two main benefits – the ability to inside an object (think of a void in a solid object), and their accuracy. At this level, we are often in the ±.001” – ±.002” range, and often used in metrology scanning.

Which scanner models do you use?

CG360

CyberGage®360 CT scanners

EasyTom S CT Scanner by RX Solutions

CMM

Surveyor ZS-Series, Surveyor DS-Series

Faro Arms

FaroArm® – Portable 3D Measurement Arm for any application

Artec

Artec Space Spider 3D Scanner, Artec Eva & Eva Lite 3D Scanner

Faro

Focus 350 Plus for long range scanning

Leica

Leica RTC360

How accurate is 3D scanning?

The scanners we use are as accurate as the industry offers – from anybody at any cost. We use Faro and Artec 3D scanners, in addition to Faro CMM type arms, including the Surveyor tables. Depending on what scanner we use:

CT scanners – 4 to 400µm/voxel resolution
Artec Portable scanners high accuracy (0.03 – 0.05mm)
Artec Portable scanners high resolution (up to 0.15mm)
Our CyberGage 360 – generates highly precise full 360 degrees automated scan with accuracy NIST traceable to approximately 7 microns
The CyberGage 360 has a system repeatability of ±.005mm.

Do you support CT scanning?

Yes with both the DeskTom and EasyTom CT scanners. They both support metrology grade Computed Tomography (CT) inspection. This provides nondestructive, 3D Scanning of Internal and External Geometries. We use the Volume Graphics VGStudio Max high-end industrial CT software for the demanding of CT applications.

Can your scanners find voids in materials?

Yes. This is one of CT scanners’ major points – to see into objects. This is the best solution for nondestructive quality control.

How good are your 3D CT scanners?

4 to 400µm/voxel resolution
Full inspection of large size samples
Modular and micro-resolution capability
6 motion axis

What is the minimum price for your scanning services?

For 3D scanning services our minimum order fee is $120.

Can you scan the internals of my parts?

Depending on the situation we can offer you dissecting your part for scanning purposes or use CT if applicable.

3D Modeling FAQs

How do you bill 3D CAD services tasks?

Per hour. Hourly rate depends on what CAD software used and typically starts at $75 per hour. In general, to make this process safer for you, we often provide you a fixed not to exceed the cost as well. That way, you are protected from an open-ended PO. However, the reality is our fees are based on time. In addition, services in say Catia or NX are more expensive than say Solidworks. Or, simulation services are commonly done by real engineers.

What do you need to give me accurate pricing?

First of all, we need to know the target CAD system and whether you have an existing template, or set of CAD standards for this project.

The main question is the overall complexity. As each part and assembly consists of different features and elements the best way is to provide us with an example. Again, a picture is worth a thousand words.

If you already have a model and need us to improve it or update it in any way we need to know which dimensions and features are critical and which can be modified to achieve your desired result. Even a before and after example works very well. We started with x, and got to this CAD file.

We can also offer you better options if you provide us with the purpose of your project (demonstration, 3D printing, FEA Simulation, CNC manufacturing, etc.). This helps us better refine the task.

How do you check your models?

We create 2D drawings from our 3D models for QC purposes. We follow aerospace standards and deliver ±.005” accuracy models for all projects. All of our QC is done by a different person than the designer. On Catia work, we often use Q-Checker for Airbus.

What is the minimum price for your 3D modeling services?

We have a minimum order fee $150.

General CAD Questions

How do I send a sample, in order to get a quote?

Fill out our quote form, attach your files, or simply send us an email. Tell everything about your project, like the model purpose.

For smaller files < 15 MB you can simply email them to us. For something larger, just drop them in any number of drop boxes like Dropbox, Google Drive, Microsoft OneDrive and others. Or if you would like, just contact us for a private, hardened link.

It is fine to use most any time of compression such as *.zip, *.rar, *.tar, *.7z, *.arc, *.LBR, and even *.iso images.

A direct email is sales@cadcam.org

We also use a hardened OwnCloud web file sharing platform for unlimited file transfers. We provide unique and very private Web Storage Portals, this also supports file syncing for extreme convenience for you. Because so much of our work is DOD or weapons design work, Security – and confidentiality is very important to us.

Will CAD / CAM Services Sign a Non-Disclosure Agreement (NDA)?

Yes. NDAs are a common part of our business. All data is yours – not ours, and treated as proprietary data and not for public consumption or use. Probably 70% of our work is under NDA agreements. We can generally get these signed within the day.

What is the estimated delivery time?

It depends on the scope of work:

2D drawings – small quantity, normally 48 hours. We have several customers where they contract to us, keeping 4-8 drafters busy full time.
3D models – complexity dependent, but smaller jobs in 2-3 days. Some models we have spent months on. Again, we have several customers where they contract to us, keeping 6-10 3D CAD designers busy full time.

Simple jobs have a lead time of 48 hours. Larger projects are delivered and invoiced weekly.

Did you really own the trademark Cad Perfect™, Cad Perfect CAD Conversions™ and Cad / Cam Services™?

Yes, we did back in 2008. We started using Cad Perfect™ back in the early 1990s because all of our customers wanted only real Cad Perfect™ work. Back then the buzz words were terms like machine ready, or DXF Traceover and others.

The problem is, nobody wanted that. They all wanted drawings and models that they did not have to touch. Everybody wanted drawings just as if they hand redrew the work themselves.

Thus, Cad / Cam Services™ was the first company to start offering ONLY Cad Perfect™ work.

Do you support the PPD-21 Directive?

Yes we do, and have now for several years. In addition, we also support the industry specific plans as well.

What is the PPD-21 Protocall?

The Presidential Policy Directive 21 (PPD-21) is a Critical Infrastructure Protection and Resilience United States directive that aims to strengthen and secure the country’s critical infrastructure.The goal of this directive is to reduce vulnerabilities, identify and disrupt threats, minimize consequences and hasten response and recovery efforts related to critical infrastructure.

The directive defines resilience as the ability to prepare for and adapt to ever changing conditions, terrorists, and withstand and recover rapidly from disruptions. Resilience includes the ability to withstand and recover from deliberate attacks, accidents, or naturally occurring threats or incidents.

Who is affected by the PPD-21 directive?

The Department of Homeland Security has identified 16 different infostructures:

Chemical Sector,
Commercial Facilities Sector,
Communications Sector,
Critical Manufacturing Sector,
Dams Sector,
Defense Industrial Base Sector,
Emergency Services Sector,
Energy Sector,
Financial Services Sector,
Food and Agriculture Sector,
Government Facilities Sector,
Healthcare and Public Health Sector,
Information Technology Sector,
Nuclear Reactors Materials and Waste Sector,
Transportation Systems Sector,
Water and Wastewater Systems Sector.

This is both Government and private sectors.

If you are in any of these industries, this directive is important to you for many reasons. Do you know where your critical sections are? Are they well protected? Are there concerns for Hazmat, security clearance requirements, and other concerns? Can you quickly rebuild what might be lost?

The important part of this means that critical infrastructure must be secure and able to withstand and rapidly recover from all hazards. Achieving this will require integration with the national preparedness system across prevention, protection, mitigation, response, and recovery.

Further details can be found at: Government PPD-21

DHS – The National Infrastructure Protection Plan details: The National Infrastructure Protection Plan

Industry specific plans: 2015 Industry specific PPD-21 plans

CAD / CAM Services provides PPD-21 for the following industries: DHS – CAD / CAM Services

I need my project done today or tomorrow. Can you process rush jobs?

Depending upon when you catch us, yes, we can handle rush jobs. We often work over the holidays, Thanksgiving and even Christmas holidays. If you have a deadline – call us.

For years we have run three shifts of about 30 drafting folks per shift – allowing us to deliver work 3x faster, and seven days a week. Yes, we work 24/7, so you do not have to. The fun never stops here.

For 3D scanning, this is a different question. Because of the common setup work required, at best expect a 48-72 hour turn to be scanned. CAD or simulation services are in addition to that.

Finite Element Analysis FAQs

What is the purpose of FEA?

A Finite Element Analysis (FEA) is a form of non-destructive testing (NDT) that shows how your part reacts to real-world loading events. A common example is running an FEA on a support bracket. The FEA will give results showing how much the bracket deflects, how much reactive force is seen, and the kind of internal stresses the bracket experiences.

‍

FEA results will change dramatically based on the position and angle of the load, how much force is applied, the material properties of the part, and the design of the part itself.

‍

An FEA is used to optimize a part before manufacturing begins. It allows you to find weak points within your part or assembly, and it will predict a failure before you physically make anything. This gives you an opportunity to fine-tune each part to optimize its size, strength, and cost before you start producing it.

What do you need to make an accurate simulation?

The more information we have, the more accurate the simulation results will be. It also depends on what type of simulation you want to run. For a simple FEA, we can run an accurate simulation with just a 3D CAD model and loading/force/pressure information that you want to simulate.

‍

Don’t have a 3D model? Not a problem, our team can make one for you from scratch, and then run an FEA on it.

‍

For a more detailed answer, a well-run FEA will need:

‍

• Material properties: What material is the part made out of? We can run different FEAs with different materials to help you pick the right one.

• Loading conditions: The size, location, and type of load you want to simulate.

• Bonding condition: How is the part held in place? Is it bolted, welded, or just sitting on a tabletop?

• A 3D model

• For other simulations: Please provide us with all thermal, dynamic, aero, and/or fluid flow information. Feel free to call us and we’ll walk you through what we need.
