CE Marking

CE Marking Services for Manufactured Goods

As a CAD and engineering services company, we support manufacturers in achieving CE marking compliance through precise design documentation, technical analysis, and regulatory alignment. Our service is designed to help ensure that your products meet the essential safety, health, and environmental requirements defined by applicable EU directives and regulations.

What We Offer

We provide end-to-end technical support for CE marking, with a strong emphasis on engineering accuracy and documentation quality. Our services include:

Product assessment and directive identification
We analyze your product to determine which EU directives and harmonized standards apply (such as Machinery Directive, Low Voltage Directive, EMC, or others).
CAD-based design verification
Using advanced CAD tools, we review and refine product designs to ensure compliance with safety and functional requirements. This includes dimensional checks, safety clearances, guarding concepts, and material considerations.
Technical documentation preparation
We create and organize the required Technical File, including CAD drawings, assemblies, risk assessments, bills of materials, and design calculations, in accordance with CE marking requirements.
Risk assessment and mitigation
We perform structured risk assessments (e.g. EN ISO 12100) and propose design modifications directly within the CAD model to reduce or eliminate identified risks.
Support for Declaration of Conformity
We assist in compiling the information required for the EU Declaration of Conformity, ensuring consistency between design data, standards applied, and product documentation.

Why Work With a CAD-Focused Partner

Unlike general compliance consultants, we approach CE marking from an engineering and design perspective. By integrating compliance requirements directly into the CAD model and technical documentation, we help minimize redesign cycles, reduce approval risks, and speed up time to market.

Our team works closely with manufacturers, product designers, and engineering departments to ensure that compliance is not an afterthought, but a built-in part of the product development process.

Industries and Products

We support CE marking for a wide range of products, including:

Industrial machinery and equipment
Mechanical assemblies and custom-built systems
Electrical and electromechanical products
Components and sub-assemblies requiring integration into CE-marked systems

A Practical Path to Compliance

Our goal is to make CE marking clear, structured, and technically sound. By combining regulatory knowledge with CAD expertise, we help you bring compliant products to the European market with confidence.
